esphome:
  name: ir-thermostat
  friendly_name: IR Thermost
  on_boot:
    priority: -100  # Run after all components are initialized
    then:
      - delay: 3s  # Wait for Tuya to finish initialization
      - lambda: |-
          id(initialization_complete) = true;
          ESP_LOGD("boot", "Initialization complete, enabling climate sync");

bk72xx:
  board: generic-bk7231n-qfn32-tuya

# Enable logging
logger:
  level: INFO

# Enable Home Assistant API
api:
  encryption:
    key: !secret ha-key

ota:
  - platform: esphome
    password: !secret ota_pass

wifi:
  ssid: !secret wifi_ssid
  password: !secret wifi_password

  # Enable fallback hotspot (captive portal) in case wifi connection fails
  ap:
    ssid: "IR Thermostat Hotspot"
    password: !secret hotspot_pass

captive_portal:

globals:
  - id: global_target_temperature
    type: float  # Changed to float to match climate component
    restore_value: yes
    initial_value: '23'

  - id: global_mode
    type: int  # Store as int for easier comparison
    restore_value: yes
    initial_value: '-1'  # -1 means "not initialized"

  - id: global_fan_mode
    type: int  # Store as int
    restore_value: yes
    initial_value: '-1'  # -1 means "not initialized"

  # Add a flag to prevent updates during initialization
  - id: initialization_complete
    type: bool
    initial_value: 'false'

  # Add a flag to track sync direction
  - id: sync_in_progress
    type: bool
    initial_value: 'false'

  # Track the source of the last change
  - id: last_change_source
    type: int
    initial_value: '0'  # 0 = unknown, 1 = primary, 2 = secondary/IR


########################
### IR BLASTER SETUP ###
########################
remote_transmitter:
  id: ir_t
  pin: P7
  carrier_duty_percent: 50%

remote_receiver:
  id: ir_r
  pin:
    number: P8
    inverted: true
  # dump:
  #   - lg
  tolerance: 55%


######################
### TUYA MCU SETUP ###
######################
uart:
  rx_pin: RX1
  tx_pin: TX1
  baud_rate: 9600

tuya:


###############
### SENSORS ###
###############
sensor:

  # WiFi signal
  - platform: wifi_signal
    name: "WiFi Signal"
    update_interval: 120s

  - platform: uptime
    name: Uptime

  - platform: tuya
    name: "Umidade"
    sensor_datapoint: 12
    unit_of_measurement: "%"

  - platform: tuya
    name: "Temperatura"
    sensor_datapoint: 2
    unit_of_measurement: "°C"
    accuracy_decimals: 1
    filters:
      - multiply: 0.1

text_sensor:
  # ESPHome version
  - platform: version
    hide_timestamp: true
    name: "ESPHome Version"
  # IP address and connected SSID
  - platform: wifi_info
    ip_address:
      name: "IP Address"
      icon: mdi:wifi
    ssid:
      name: "Connected SSID"
      icon: mdi:wifi-strength-2

binary_sensor:
  - platform: status
    name: Status


#######################
### CLIMATE DEVICES ###
#######################
climate:
# THIS IS THE TUYA CLIMATE ENTITY
# IT RELAYS STATE CHANGES TO THE SECONDARY CLIMATE ENTITY WHICH PROCESSES THEM AS IR COMMANDS
  - platform: tuya
    name: "AC"
    id: climate_primary
    visual:
      min_temperature: 17
      max_temperature: 30
      temperature_step: 1
    switch_datapoint: 1
    target_temperature_datapoint: 3
    target_temperature_multiplier: 1
    current_temperature_datapoint: 2
    current_temperature_multiplier: 0.1
    supports_heat: true
    supports_cool: true
    active_state:
      datapoint: 4
      cooling_value: 0
      heating_value: 1
      fanonly_value: 3
      drying_value: 4
    fan_mode:
      datapoint: 5
      auto_value: 0
      low_value: 1
      medium_value: 2
      high_value: 3

    # AUTOMATION THAT WHENEVER THE DATAPOINTS UPDATE THOSE STATUSES SHOULD ALSO BE UPDATED ON THE MAIN CLIMATE ENTITY
    on_state:
      - lambda: |-
          // Skip if this change was triggered by secondary sync
          if (id(sync_in_progress)) {
            ESP_LOGD("climate_sync", "Sync in progress, skipping primary->secondary sync");
            return;
          }

          // Skip updates during initialization
          if (!id(initialization_complete)) {
            ESP_LOGD("climate_sync", "Skipping update - initialization not complete");
            return;
          }

          auto primary = id(climate_primary);
          auto secondary = id(climate_secondary);

          // Skip if target temperature is NaN
          if (std::isnan(primary->target_temperature)) {
            ESP_LOGD("climate_sync", "Skipping update - target temperature is NaN");
            return;
          }

          // Mark that we're syncing from primary
          id(last_change_source) = 1;

          ESP_LOGD("climate_sync", "=== Primary -> Secondary Sync ===");

          bool needs_update = false;
          auto call = secondary->make_call();

          // Check temperature change
          if (!std::isnan(primary->target_temperature) &&
              (std::isnan(id(global_target_temperature)) ||
               std::abs(primary->target_temperature - id(global_target_temperature)) > 0.1)) {
            ESP_LOGD("climate_sync", "Temperature changed: %.1f -> %.1f", id(global_target_temperature), primary->target_temperature);
            id(global_target_temperature) = primary->target_temperature;
            call.set_target_temperature(primary->target_temperature);
            needs_update = true;
          }

          // Check mode change
          int current_mode = (int)primary->mode;
          if (current_mode != id(global_mode)) {
            ESP_LOGD("climate_sync", "Mode changed: %d -> %d", id(global_mode), current_mode);
            id(global_mode) = current_mode;
            call.set_mode(primary->mode);
            needs_update = true;
          }

          // Check fan mode change
          if (primary->fan_mode.has_value()) {
            int current_fan_mode = (int)primary->fan_mode.value();
            if (current_fan_mode != id(global_fan_mode)) {
              ESP_LOGD("climate_sync", "Fan mode changed: %d -> %d", id(global_fan_mode), current_fan_mode);
              id(global_fan_mode) = current_fan_mode;
              call.set_fan_mode(primary->fan_mode.value());
              needs_update = true;
            }
          }

          // Only perform call if something actually changed
          if (needs_update) {
            ESP_LOGI("climate_sync", "Sending update to secondary climate");
            id(sync_in_progress) = true;
            call.perform();
            id(sync_in_progress) = false;
          }

  # THIS THE THE SECONDARY HIDDEN CLIMATE DEVICE THAT PROCESSES THE COMMANDS FROM THE PRIMARY ENTITY AS IR COMMANDS

  - platform: climate_ir_lg
  # Exampels of other platforms tested with this config
  # - platform: midea_ir
  # - platform: heatpumpir
    name: "IR"
    id: climate_secondary

    # If using platform: heatpumpir, uncomment this and select the correct procotol accordingly
    # protocol: electroluxyal
    # horizontal_default: auto
    # vertical_default: auto
    # min_temperature: 16
    # max_temperature: 30

    receiver_id: ir_r

    # AC Units from LG in Brazil use these timings. May not be required for your case.
    header_high: 3265us
    header_low: 9856us

    internal: true
    visual:
      min_temperature: 17
      max_temperature: 30
      temperature_step: 1

    on_state:
      - lambda: |-
          // Skip if this was triggered by primary sync
          if (id(sync_in_progress)) {
            ESP_LOGD("climate_sync", "Sync in progress, skipping secondary->primary sync");
            return;
          }

          // Skip during initialization
          if (!id(initialization_complete)) {
            ESP_LOGD("climate_sync", "Initialization not complete, skipping IR sync");
            return;
          }

          auto secondary = id(climate_secondary);
          auto primary = id(climate_primary);

          // This is likely an IR remote command if we got here
          ESP_LOGD("climate_sync", "=== IR Remote Command Detected ===");
          ESP_LOGD("climate_sync", "Mode: %s", climate_mode_to_string(secondary->mode));
          ESP_LOGD("climate_sync", "Target Temp: %.1f", secondary->target_temperature);
          if (secondary->fan_mode.has_value()) {
            ESP_LOGD("climate_sync", "Fan Mode: %s", climate_fan_mode_to_string(secondary->fan_mode.value()));
          }

          // Mark that we're syncing from secondary
          id(last_change_source) = 2;

          // Check what changed and update primary
          bool needs_update = false;
          auto call = primary->make_call();

          // Temperature
          if (std::abs(secondary->target_temperature - id(global_target_temperature)) > 0.1) {
            ESP_LOGD("climate_sync", "IR changed temperature: %.1f -> %.1f",
                     id(global_target_temperature), secondary->target_temperature);
            id(global_target_temperature) = secondary->target_temperature;
            call.set_target_temperature(secondary->target_temperature);
            needs_update = true;
          }

          // Mode
          int secondary_mode = (int)secondary->mode;
          if (secondary_mode != id(global_mode)) {
            ESP_LOGD("climate_sync", "IR changed mode: %d -> %d",
                     id(global_mode), secondary_mode);
            id(global_mode) = secondary_mode;
            call.set_mode(secondary->mode);
            needs_update = true;
          }

          // Fan mode
          if (secondary->fan_mode.has_value()) {
            int secondary_fan_mode = (int)secondary->fan_mode.value();
            if (secondary_fan_mode != id(global_fan_mode)) {
              ESP_LOGD("climate_sync", "IR changed fan mode: %d -> %d",
                       id(global_fan_mode), secondary_fan_mode);
              id(global_fan_mode) = secondary_fan_mode;
              call.set_fan_mode(secondary->fan_mode.value());
              needs_update = true;
            }
          }

          if (needs_update) {
            ESP_LOGI("climate_sync", "Syncing IR changes to Tuya");
            id(sync_in_progress) = true;
            call.perform();
            id(sync_in_progress) = false;
          }
